10kWh Solar Power System Package

10kWh Solar Power System Package | SRNE 10kVA Hybrid Inverter + 10.24kWh Lithium Battery + 12 Jinko Solar Panels

The 10kWh Solar Power System Package is a complete energy solution designed for homes, offices, farms, and small businesses seeking reliable solar power generation and energy storage. The system combines a high-performance SRNE 10kVA Hybrid Inverter, a 10.24kWh SRNE LiFePO₄ Lithium Battery, and 12 high-efficiency Jinko Solar Panels (600W or 620W), providing efficient solar energy generation, storage, and utilization.

Designed for both grid-connected and backup power applications, the system intelligently manages solar power, battery storage, and utility electricity to maximize energy efficiency and support continuous power availability.

System Components

SRNE 10kVA Hybrid Inverter

  • 10kVA / 10,000W rated output power
  • Pure sine wave output
  • Hybrid inverter with built-in MPPT solar charger
  • 48V battery system compatibility
  • High-frequency inverter technology
  • Lithium battery communication support
  • WiFi monitoring capability
  • Parallel operation support
  • Intelligent battery charging management
  • LCD display for system monitoring

SRNE 10.24kWh Lithium Battery

  • 51.2V nominal voltage
  • 200Ah battery capacity
  • 10.24kWh usable energy storage
  • LiFePO₄ battery technology
  • Integrated Battery Management System (BMS)
  • Long cycle life
  • RS485/CAN communication support
  • Wall-mounted or rack-mounted installation options
  • Suitable for solar energy storage applications

Jinko Solar Panels

  • 12 high-efficiency solar panels
  • Available in 600W or 620W modules
  • Total solar array capacity:
    • 7.2kW (12 × 600W)
    • 7.44kW (12 × 620W)
  • Monocrystalline solar cell technology
  • Designed for residential and commercial solar installations
  • Reliable performance under varying weather conditions

Installation Accessories Included

  • Solar DC cables
  • MC4 connectors
  • Mounting hardware and accessories
  • Battery interconnection cables
  • AC and DC protection accessories
  • Earthing and safety components
  • System monitoring accessories (where applicable)

Suitable Applications

  • Residential homes
  • Offices and commercial premises
  • Farms and rural electrification
  • Schools and institutions
  • Backup power systems
  • Energy storage installations
